Vividia SV-0-07810 Flexible Video Borescope Ultra Thin 0.78mm Diameter 1m Long Probe 5" Touchscreen Monitor

Vividia SV-0-07810 Flexible Video Borescope is a flexible non-articulation videoscope with 0.78 mm diameter probe head and 1 meter long probe insertion tube and a side-view camera. The camera resolution is 200x200 and the LCD monitor has 5" touchscreen with snapping and recording functions. The photos and videos are saved on a SD card. The probe is waterproof and protected with metal braided mesh layers for wear and tear in harsh industrial environments. SV-0-07810 is possibly one of the smallest camera with lighting you can buy in the world.

Vividia SV-0-07810 borescope is a good choice for applications where articulation feature is not required, but small diameter camera is very important, and close focus is required.

Main Features of SV-0-07810 slim video borescope:

• 0.78mm / 0.031" diameter slim thin camera head with 200x200 CMOS image sensor
• Flexible 1m / 3ft long ultra thin probe
• Built-in 5W LED light with optical fiber guide for probe tip lighting
• 5" touchscreen monitor with picture and video recording functions
• Waterproof probe camera IP67
• Rechargeable lithium battery

Note: This is the one of the smallest diameter video borescope with a resolution of 200x200 we have so far (2025). Another model close to this one is VP-0-08506 (400x400 resolution, 2025). Other smaller diameter scopes will be fiberscopes (optical fiber bundles), such as ET-055, ET-078 fiberscopes.

SV-0-07810 video borescope, 200x200 resolution, 1m long probe

SV-0-07820 video borescope, 200x200 resolution, 2m long probe

VP-0-08506 video borescope, 400x400 resolution, 0.6m long probe. This is longest probe we can do at the moment with good image quality.

These two models are probably the smallest video borescopes you can buy. Maybe the smallest camera with built-in lighting in the world in terms of the camera diameter.

Note:

1. Use extreme care when handling the 0.78mm diameter probe. Do not bend the probe with a sharp angle. Do not hit it with a heavy object or strong force. Put the probe in the metal protective sleeve when not in use.
2. While the 0.78mm diameter camera is our smallest diameter video scope, its resolution is low at 200x200. We recommend that you choose the 0.95mm or larger diameter scopes if those work with your applications. The larger the diameter, better the image quality and more durable the probe.

Pictures taken with SV-0-07810 video borescope, 0.78mm diameter.

A video with SV-0-07810 video borescope:

If you need a rigid version of this 0.78mm diameter inspeciton video borescope, please contact us for customerization. See below for an example. The rigid model is SV-R-07806 for 0.78mm diameter camera head, and 60mm long rigid probe.
